Specifications

• Dimensions

  add remove
  • Length:
    94.3 in
  • Ground clearance:
    4.8 in
  • Rake (steering head):
    32 degrees
  • Trail:
    5.8 in
  • Wheelbase:
    64.5 in
  • Tires, front specifications:
    D402F MT90B16 72H
  • Tires, rear specifications:
    D401 150/80B16 71H
  • Fuel Capacity:
    5.0 gal
  • Oil capacity:
    3.48707 qt.
  • Weight, as shipped:
    728 lbs
• Engine

  add remove
  • Engine:
    45 Aircooled Twin Cam 103BT (balanced)
  • Bore:
    3.9 in
  • Stroke:
    4.4 in
  • Displacement:
    103.13 in³
  • Compression ratio:
    8.8:1
  • Fuel system:
    Electronic Sequential Port Fuel Injection (ESPFI)
• Performance

  add remove
  • Engine torque:
    100.3 ft-lb
  • Engine torque (RPM):
    4000
  • Lean angle, right (deg.):
    29º
  • Lean angle, left (deg.):
    27º
• Powertrain

  add remove
  • Primary drive:
    Double row chain, oil bath, mechanical tensioner, 36/25 ratio
  • Gear ratios (overall) 1st:
    10.11
  • Gear ratios (overall) 2nd:
    6.96
  • Gear ratios (overall) 3rd:
    4.95
  • Gear ratios (overall) 4th:
    3.87
  • Gear ratios (overall) 5th:
    3.15
  • Final drive:
    carbon fiber reinforced polychain belt, 32/70 ratio
  • Clutch:
    9-Plate, wet
  • Transmission:
    Five-speed
• Chassis

  add remove
  • Front fork:
    41.3 mm, Telescopic w/ "beer can" covers
  • Wheels, front type:
    Polished spun aluminium solid
  • Wheels, rear type:
    Polished spun aluminium solid
  • Brakes, caliper type:
    Four-piston front and rear
  • Frame:
    Mild steel, rectangular section backbone w/ twin down-tubes
  • Swingarm:
    Triangular "hard tail" style
• Electric

  add remove
  • Lights (as per country regulation), indicator:
    High beam, neutral, oil, turn signals and security system
  • Lights (as per country regulation), Headlamp:
    Quartz halogen, 55-watt low beam, 60-watt high beam
  • Lights (as per country regulation), Tail/Stop:
    5w/21w
  • Lights, front signal lights:
    21w
  • Lights, rear turn signals:
    21w
  • Battery:
    Sealed, maintenance-free, 12-volt, 19 amp-hour, 270 cca
  • Charging:
    38-amp permanent magnet alternator w/ solid-state regulator (439 watts @ 2000 rpm; 489 watts peak)
  • Starting:
    1.4 kw electric w/ Bendix-type engagement
